Overview Imagestore 750 User Manual
Page 48 Miranda Technologies Inc.
Option Description
IS-750-DOLBY-DEC2 Two Dolby decoder modules
IS-750-DOLBY-DEC2-ENCE Two Dolby decoder modules + Dolby E
encoder module
IS-750-DOLBY-DEC2-ENCD Two Dolby decoder modules + Dolby Digital
(AC3) encoder module
IS-750-DOLBY-ENCE Dolby E encoder module
IS-750-DOLBY-ENCD Dolby Digital (AC3) encoder module
IS-750-UMX Up-Mix module
IS-750-DOLBY-DEC-UPG +1 Dolby E decoder upgrade
IS-750-DOLBY-ENCE-UPG +1 Dolby E encoder upgrade
IS-750-DOLBY-ENCD-UPG +1 Dolby Digital (AC3) encoder upgrade
IS-750-UMX-UPG +1 Up-Mix module upgrade
The Imagestore 750 LOGO is a branding-only product. From a hardware
perspective, it is identical to the standard Imagestore 750; however the
following features are disabled:
•
AB mixing
•
C/D inputs (Fill-3/Key-3)
•
Clean Feed
•
Monitor Feed
If these features need to be enabled at a future date is possible to upgrade to a
standard Imagestore 750 by purchasing the appropriate licences.
The IS-750-Audio6-75/110 and IS-750-Audio16-75/110 options include an
appropriate audio break-out cable hardware option – (product codes ABT-32-
32-D75 and ABT-32-32-D110). These comprise of a SCSI connector cable
(pin-out described on page 274) and a 1RU break-out box which allows easy
connection of 75R or 110R AES.
If the IS-750-EAS option is purchased without the IS-750-Audio6 or IS-750-
Audio16 option, then a stereo audio break-out cable (product code 1872-
