Front Panel Operations
Imagestore 750 User Manual
Page 56
Miranda Technologies Inc.
The factory default setting for each input is Pass-SDI, although any of the
three colour fields or two test patterns can be selected instead.
Using the front panel control joystick controls (⊳ enter) select the input
you wish to modify and select the setting that you wish this input to take.
Pass SDI
Selects the incoming SDI signal to be used for the selected input.
Colour Field 1
Selects the first colour field to be used for the selected input.
Colour Field 2
Selects the second colour field to be used for the selected input.
Colour Field 3
Selects the third colour field to be used for the selected input.
Test Pattern 1
Selects the first (internally generated) test pattern to be used for the input.
Test Pattern 2
Selects the second (internally generated) test pattern to be used for the input.
