Standard Mixfiles Imagestore 750 User Manual
Page 296 Miranda Technologies Inc.
16chn_AB_eply.mix PGM Video 16
16chn_AES_AB.mix PGM Video
AES 1-8
16
16chn_AES_AB_eply.mix PGM Video
AES 1-8
16
32chn_AES_pass.mix AES 1-16 32
5.1_dualVO.mix PGM Video 6
5.1_VO_eply.mix PGM Video 6
5.1_AES_dualVO.mix PGM Video
AES 1-3
6
5.1_AES_VO_eply.mix PGM Video
AES 1-3
6
5.1_IntuitionVO.mix PGM Video 6
7.1_dualVO.mix PGM Video 8
7.1_VO_eply.mix PGM Video 8
7.1_AES_eply.mix PGM Video
AES 1-4
8
Imagestore 2/3 Emulation Mixfiles
is23.mix & is23eply.mix
For the Imagestore 2/3 emulation mixfiles, a ‘group’ refers to a collection of
four mono inputs. Mixing occurs between the group currently selected for
Program (PGM) and the group selected for Preset (PST). Further still,
selectable cross-points for each channel allow mapping of both groups for the
mix.
The operation of the Imagestore 2/3 emulation mixfiles remains unchanged
compared with earlier versions of the Imagestore software. However to
improve usability (especially as part of a Presmaster based Master Control
environment) the following features are now supported:
