Imagestore 750 User Manual Standard Mixfiles
Miranda Technologies Inc. Page 299
16chn_AB.mix
This mixfile is designed for 16 channel embedded AB mixing, with dual AES
(8 channel) voice overs and embedded output. It collects embedded audio
from the A and B inputs for standard AB mixing. Dual voice over insertion
is possible on the first 8 channels of the AB mix.
Each voice-over control (i.e. VO 1 pair 1 and VO 2 pair 1) controls an 8
channel voice-over insertion onto the first 8 channels of the embedded
output. Both of these voice-overs source their audio from the AES inputs.
The physical voice-over inputs are as follows…
•
First voice-over (VO 1 Pair 1 channels 1-8) = AES inputs 1–4
•
Second voice-over (VO 2 Pair 1 channels 1-8) = AES inputs 5-8
Note: These voice-overs were selected to allow for dual voice-over
control in a Presmaster master control environment
16chn_AB_eply.mix
This mixfile is designed for 16 channel embedded AB mixing, with single
AES voice over plus Easyplay onto embedded output. It collects audio from
the A and B inputs for standard AB mixing. All 8 channels of Easyplay can
be inserted (on a one-to-one basis) onto the first 8 channels of the AB mix
output (controlled by the first voice over). External voice over insertion is
also possible on the first 8 channels of the AB mix using AES inputs
(controlled by the second voice over).
The physical voice-over inputs are as follows…
•
Second voice-over (VO 2 Pair 1 channels 1-8) = AES inputs 5-8
16chn_AES_AB.mix
This mixfile is designed for 16 channel AES AB mixing onto AES and
embedded output. It collects audio from the AES input pairs 1-8 and 9-16 for
standard AB mixing.
There are no physical voice-over inputs.
