Up-Mix Imagestore 750 User Manual
Page 392 Miranda Technologies Inc.
The preset metadata parameters for are defined within the Configurator tool
and transferred to the unit via a configuration file. Once transferred,
individual user-defined preset files can then be loaded into the internal
metadata “banks” via automation.
Once a user-defined preset is loaded into an internal “bank”, its values can be
over-ridden by subsequent automation commands. This does not affect the
original user-defined preset, just the values currently in use.
Please see page 365 within the Dolby chapter for further information in
individual metadata parameters.
Automation Control
Automation commands can be used to control some aspects of the audio
modules and to change internal metadata source values. The internal sources
of Metadata are termed a “banks”, and there are four available banks.
The metadata commands are summarised on page 378.
Please refer to version 15 (or higher) of the Oxtel Automation Protocol
document for details of the command formatting and parameters
Up-Mix Modules
The Up-Mix function may be set via the q0 automation command. This
allows the module to be set into one of the following modes:
•
0 = Passthrough
•
1 = Enable
•
2 = AutoMD (follow metadata)
Please refer to version 15 (or higher) of the Oxtel Automation Protocol
document for details of the command formatting and parameters.
