24 GND
25 GND
26 GND
27 RS232A_TX (reserved for future use)
28 RS232A_CTS (reserved for future use)
29 RS232A_RTS (reserved for future use)
30 RS232B_CTS (reserved for future use)
31 LTC+
32 GP_GND
33 GPIO_16
34 GPIO_14
35 GPIO_12
36 GPIO_10
37 TOTAL_DC_FAIL
38 GPIO_9
39 GPIO_7
40 GPIO_5
41 GPIO_3
42 GPIO_1
43 RS232A_RX (reserved for future use)
44 RS232B_RX (reserved for future use)
Connector type: 44 pin female D type
Miranda offers a 44-way GPIO adapter to assist connecting to this connector,
GPIO-44TBA.
Note: For details on the 25-way GPIO port on earlier Imagestore 750
units, please refer to User Manual v1.14.0 or v1.14.1.
IS-25-44-ADP is the order code for a 25-pin to 44-pin adaptor that allows
wiring designed for the 25-pin GPI/LTC connector to be used with the
44-pin GPI/LTC connector.
