2-72

Section 2 —

Installation

The following table lists S1 switch settings and the resulting
source offset. An “O” indicates an

open

segment; a “C” indicates a

closed

segment.

Table 2-17. Performer Source Offset

Sources

S1 #1

S1 #2

S1 #3

1-10

O

O

O

11-20

O

O

C

21-30

O

C

O

31-40

O

C

C

41-50

C

O

O

51-60

C

O

C

61-70

C

C

O

71-80

C

C

C
