Grass Valley Performer SD - Manual (Page 131)

3-13
TEN-XL Control Panels Operation
Performer Display During 19 x 1 Operation
The displays of the Performers will tally the sources switched at
their inputs, but will not tally from 1 to 19: The
secondary
Performer will tally 2 through 10, and then switch back to
displaying Source 1 when source 10 is selected. It will continue to
display source 1 as long as sources 10 through 19 are selected. The
primary Performer will talley sources 10 through19 but display 1
through 10, respectively. The display will return to 1 when sources
1 through 9 are selected.
NOTE: You can accidentally initiate a breakaway state from the
front panel of a Performer. If you do, immediately press any
buttons on the TNX-AFV19 panel. The breakaway state will
cease.
Primary
Performer
Secondary
Performer
TNX-
AFV19
Control
Panel
Control
Control
Sources
10–19
Sources
1–9
Output of
Primary
Performer
Output of
Secondary
Performer 19 x 1 Output
Use caution when using 19 x
1 configuration for live or on-
air switching. Undesired
switching effects may result
when switching from a
source in the primary to a
source in the secondary.
