Destination Offset
Segments 4, 5, and 6 of switch S1 determine destination offset. The
segments operate in binary fashion (4 most significant; 6 least) to
select destination offsets from 0 to 7. When a destination offset of
0 is selected, the Performer destination is 1. If a destination offset
of 1 is selected, the Performer destination is 11. When a destination
offset of 2 is selected, the Performer destination is 21. This
sequence continues through a destination offset of 7 and a
destination of 71.
The following table lists S1 switch settings and the resulting
destination offset. An “O” indicates an
open
segment; a “C”
indicates a closed segment.
Table 2-10. Performer Destination Offset
Destination
S1
#4
S1
#5
S1
#6
1
O
O
O
11
O
O
C
21
O
C
O
31
O
C
C
41
C
O
O
51
C
O
C
61
C
C
O
71
C
C
C
