2-17
Common Configurations
PC (TEN-XL ASCII) to Performer (cont.)
The following is an example of a TEN-XL ASCII string used to
control a Performer via a PC. The command string will switch
video input number 4 and both audio channels to input number 6.
TEN-XL ASCII protocol does not allow left and right audio
channel breakaway.
TEN-XL ASCII command string: ^B0035
*The video and audio crosspoints are numbered 0 through 9.
Table 2-2.
ASCII Description
Byte 1 ^B start of transmission
Byte 2 00 Performer address
Byte 3 35 video crosspoint 4*
audio crosspoint 6*
