2-63
Control Panel Reference
Panel Operating Mode
To select operating mode, locate segment 5 on SCP switch S1.
To select Dual Mode (two Performers only):
■ Close segment 5.
To select X–Y Mode (up to ten Performers):
■ Open segment 5.
Normal & Diagnostic Mode
In order to operate, the SCP must be in the Normal Mode. The
Diagnostic Mode is reserved for panel test and is described in the
TEN-XL Service Manual .
To select Normal Mode:
1. Locate segment 6 on SCP switch S1.
2. Close segment 6.
Modem Compatibility
The SCP will work with a Hayes compatible modem. If you are
using a modem, you must set segment 7 of switch S1 accordingly.
If you are using a modem:
■ Open segment 7.
If you are not using a modem:
■ Close segment 7.
NOTE: S1, segment 8 is NOT USED.
