 QC-300 Series User’s Guide
Speaker and external speaker jack outputs are provided that can be adjusted for quiet or noisy environ-
ments. Ear phones can be plugged into the external speaker jack to facilitate silent operation in quiet
environments.
Sequences of key-presses and touch probe contacts used to perform measurements can be recorded and
stored as programs. These programs can be replayed later to perform complete measurement sequences.
Sequences can be as simple as measuring a line, or can be expanded to include skew adjustment, datuming,
the measurement of multiple features, tolerancing and printing reports of measurement results.
Measurement results can be saved to a USB flash drive, transmitted to a PC over the RS-232 port or printed
on a USB printer.
Wide keys
LCD ON/OFF
Command keys
Numeric keypad
Print/Send data
Touch screen
controls
Color touch
screen
