Programming: Multiple Axis Machining
12.2 The PLANE Function: Tilting the Working Plane (Software Option 1)
12
372
TNC 640 | User's Manual for DIN/ISO Programming | 5/2013
Resetting the PLANE function
Show the soft-key row with special functions
Select special TNC functions: Press the SPECIAL
TNC FUNCT. soft key
Select the PLANE function: Press the TILT
MACHINING PLANE soft key: The TNC displays the
available definition possibilities in the soft-key row
Select the Reset function. This internally resets the
PLANE function, but does not change the current
axis positions
Specify whether the TNC should automatically
move the rotary axes to the default setting
(MOVE
or TURN) or not (STAY)See "Automatic positioning:
MOVE/TURN/STAY (entry is mandatory)",
page 385.
Terminate the entry: Press the END key
The PLANE RESET function resets the current PLANE
function—or an active cycle G80—completely (angles
= 0 and function is inactive). It does not need to be
defined more than once.
NC block
25 PLANE RESET MOVE ABST50 F1000
