RISCO Group ACIS - Manual (Page 24)

User Manual for ACIS Version
Uncontrolled when printed © RISCO Group 15
Field Name Description
configured and running on the machine where
DCC is installed.
GSM Proxy can use the Global System for Mobile
communications to communicate with the RSP server. To
do that, the GSM services need to be enabled.
The User Name, Password and Access Point Name are
reflected based on the configuration file. If the
configuration file has no data, then these fields will be
blank.
Enter the GSM details in these fields.
Note: When you enter the credentials, please ensure
that you have connected the GSM modem to the
proxy. Leave blank in case there you are not
using GSM modem.
Dial Up Proxy can use the Dial up or Public Switched Telephone
Network (PSTN) to communicate with the RSP server
The User Name, Password and Access Point Name are
reflected based on the configuration file. If the
configuration file has no data, then these fields will be
blank.
Enter the Dial Up details in these fields.
Note: When you enter the credentials, please ensure
that you have connected the PSTN modem to the
proxy. Leave blank in case there you are not
using PSTN modem.
Enable System Log Select this check box to enable system log for this proxy. By
default, the check box is enabled and the installer cannot
edit it, but can only select the type of log as required.
Note: There are three levels, Critical, Debug and Info.
Critical is enabled by default. If the user selects
Debug, then the debug info along with the critical
will be logged. If user selects Info, all three levels
of the messages will be logged.
3. Click Apply. The system displays a message, “Proxy configured successfully”.
or
• Click Apply and Close. The changes are reflected and the window is closed. The home page appears.
or
