Document Number: 104461 Revision: F
Date: 03/13/14
Template: 4.4.1.6FM2; Revision A; 12/06/12 Page 30 of 32
Description Section Category Comments
Emission of Radio Frequency Energy 21
Conducted RF Emission 21.4 M
Radiated RF Emission 21.5 M
Electrostatic Discharge (ESD) 25
Electrostatic Discharge (ESD) 25.5 A
Flammability 26
N/A
Flammability testing in
accordance with 14 CFR
25.853 Appendix F
10.4. Specifications
See the appropriate Outline and Installation drawings on the Rosen Aviation website for display
specifications.
10.4.1. Supported Composite/Composite Resolutions
NTSC (480i/29)
PAL (576i/25)
SECAM (576i/25)
RS-170 B&W (480i/29)
10.4.2. Supported SDI Resolutions
480i/29
576i/25
720p/50, 720p/59, 720p/60
1080i/25, 1080i/29, 1080i/30
1080p/23, 1080p/24, 1080p/25, 1080p/29, 1080p/30, 1080p/50, 1080p/59, 1080p/60
11. DEFINITIONS
3G HD-SDI
Newer, high-definition serial digital interface with a single 2.970 G/bit/s serial
link
AF
Audio frequency
AGC
Automatic Gain Control
CFR
Code of Federal Regulations
CS
Conducted susceptibility
CVBS
Composite video blanking and sync
DC
Direct Current
DVI
Digital Visual Interface
EUT
Equipment under test
HD
High Definition
