- 22 -
Fig.5-18
Step
Parts to remove
Remarks and procedures
Fasteners
22
Main bearing cover
Remove the flange bolts of main bearing cover from
the crankcase.
Remove the main bearing cover while tapping gently
around the cover using a plastic hammer or similar
tool. (See Fig. 5-18)
Be careful not to damage the oil gauge or oil seal or
not to lose the pipe knocks.
12 mm box spanner
M8 x 38mm : 8 pcs.
Fig.5-17
MAIN BEARING COVER
M8 x 38 BOLT : 8 pcs.
PIPE KNOCK
STEP 22
