Reference PTQ-PDPMV1 ♦ Quantum Platform
User Manual PROFIBUS DP Master Network Interface Module for Quantum
Page 246 of 306 ProSoft Technology, Inc.
August 12, 2014
9.1.3 Hardware Specifications
Specification Value
Backplane Current Load 1100 mA maximum @ 5 Vdc ± 5%
Operating Temperature 0°C to 60°C (32°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Relative Humidity 5% to 95% (with no condensation)
Vibration Sine vibration 4-100 Hz in each of the 3
orthogonal axes
Shock 30 g, 11 mSec. in each of the 3 orthogonal axes
Dimensions (HxWxD), Approx. 250 x 103.85 x 40.34 mm
9.84 x 4.09 x 1.59 in
LED Indicators Module Status
Backplane Transfer Status
Serial Port Activity LED
Serial Activity and Error LED Status
Master Status Operations
Network Drop Communication
Master Token-Hold
Master database configuration
Debug/Configuration Ports
Configuration Serial Port (PRT1) DB-9M PC Compatible
RS-232 only
No hardware handshaking
Configuration Ethernet Port RJ45 Connector
Link and Activity LED indicators
Application Port
PROFIBUS Master Port DB-9F Optically Isolated RS-485
Ready, Run, Error and Token LED Indicators
