8.10.4. CV/Gate settings
This is where you select the electrical behavior for the Control Voltage connectors.
Here’s a quick reference chart for these parameters.
Parameter Range/Values Description/Function
PITCH CV
Output
Volts per octave [*] Hertz
per volt [**] The two standards. Each uses a different MIDI note
reference
[*]0 Volt MIDI
Note
Full MIDI range for center [*] With Volts per Octave
[**]1 Volt MIDI
Note
Full MIDI range for center [**] With Hertz per Volt
Note Priority Low, High, Last Specifies the response of monophonic devices
MOD CV source
Mod strip, Velocity,
Aftertouch
Determines which KeyStep feature drives the Mod CV
MOD CV max
voltage
5-12 Volts
Minimum = 0 Volts in all cases; maximum can be 5 to 12
volts.
Pitch Bend
Range
1-24 semitones
Chooses how much the Pitch CV will vary when the Pitch
strip is used.
GATE CV Output S-trig, V-trig 5V, V-trig 12V
‘Short/negative’ trigger and two common types of ‘Voltage/
positive’ triggers.
Now we’ll take a look at each of those parameters.
8.10.4.1. Pitch CV Output
The various models of vintage gear respond differently to electricity. KeyStep works well
with the most common types.
• 1Volt per octave – This is the standard used on most Eurorack modules and on
our very own Mini- and MicroBrute synthesizers.
• Hertz per volt – This is the technology used by Korg and older Yamaha
synthesizers.
