1. OVERVIEW
1.1. Making the connections
There are quite a few ways to connect KeyStep with other types of equipment, from vintage
to modern. Below are some examples of potential setups:
1.1.1. …with a Computer
KeyStep is a USB class-compliant controller, so at its most basic level it can be connected
to any computer with a USB port and used as an input device for various applications. The
included MIDI Control Center software lets you choose which MIDI messages will be sent
by the mod strip and pedal, and also enables you to specify the global KeyStep parameters.
However, KeyStep can also be used without a computer attached! In this case, simply use a
9V DC power supply (not included) or a standard USB mobile phone charger to power the
unit. Then connect everything else as shown in the following diagrams.
1.1.2. …with external devices
As you can see, KeyStep can be at the center of some amazing systems.
1.1.2.1. CV/Mod/Gate
KeyStep will send control voltages to non-MIDI devices through its Pitch, Mod and Gate
connectors. It also can send data to those devices from the USB port of your computer.
Arturia - User Manual KeyStep - Overview
4
