Canon Mk1500 Cable and Wire Marker Printer - Manual (Page 100)

96
5.2
What To Do If the Cutter Is Getting Blunt
Changing the cutting depth
If the cutter does not cut tube or label tape properly, try changing the cutting depth. The cutting depth for half
cuts and for full cuts can be adjusted as described below. In addition, these adjustments can be made separately
for each type of print media.
If half cuts are made so deeply that they completely cut through the tube, adjust cutting to a shallower depth.
Note that a deeper cutting depth will cause the cutter and the cutter receiver to wear out more quickly.
Half cut
Deeper cut
Shallower cut
Deeper cut Deep 3
Deep 2
Deep 1
Normal
Shallow 1
Shallow 2
Shallow 3
Full cut
Deep 3
Deep 2
Deep 1
Normal
ex. Full cuts of label tape are not complete cuts, so increase the cutting depth by one step.
1
Press [Option].
The setting display appears. •
2
Press [ ◄ ] or [ ► ] to select “1:Adjustment”, and press Adjustment
mode [Enter].
The Adjustments display appears. •
3
Press [ ◄ ] or [ ► ] to select “4:Full-cut”, and then press Select
media [Enter].
The Select media display appears. •
