27

Basic Operations

Part 2

3

Install the ribbon cassette into the printer.

Push the cassette in until it clicks into place.

If the ribbon cassette is loose, the ribbon may not be detected, so be sure to press it in until
it clicks.

CAUTION

Do not touch the connector (metal part)

Do not hold the connection terminal (metal part) of the cassette. Doing so could cause an
improper recognition of the cassette.

4

Install the tube attachment into the printer.

Align the tabs on the tube attachment with the
holes in the printer, and then push the tube
attachment in until it clicks into place.

5

Remove the wrap-around tape guide.

page 18.

6

Close the cover.

Close the cover completely so that it clicks shut.

Two cassettes

Two cassettes shown below are supplied with the printer.

Ink ribbon cassette

The ink ribbon cassette contains a ribbon that contains
special ink. The ink is printed on a tube or label tape by
applying heat to the ribbon.

Tube attachment

The tube attachment is used to print characters on a tube. It
feeds a tube into the printer.
