Featured Device

Featured
Device

The Transceiver SI Development Kit, Stratix II GX Edition features the
EP2SGX90EF1152 FPGA (U20) in a 1152-pin FineLine BGA

®

(FBGA)

package.

Table 2–2

lists some Stratix II GX device features.

f

For additional information about Altera devices, go to
www.altera.com/products/devices

.

Power Supply

Input

DC power
jack

J16

16-V DC unregulated power source.

2–25

Input

Power switch

S10

Switches the board’s power on and off.

2–25

Input

Optional
power input
connection
jacks

J17, J15,
J18, J19,
J20, J21

External power supply can be connected for high current
applications.

2–25

Input

Jumper
header

J50

Jumper header for selecting between 1.5-V DC and
1.2-V DC supplied to the quad transceivers. Jumper pins 1
and 2 select 1.5-V output, and jumper pins 2 and 3 select
1.2-V output.

2–25

Output

Temperature
sensor

U17

Performs thermal management, i.e., turning the cooling fan
on and off to regulate the FPGA temperature.

2–25

Table 2–1. Stratix II GX Transceiver SI Development Board Components & Interfaces (Part 3 of 3)

Type

Component/

Interface

Board

Reference

Description

Page

Table 2–2. Stratix II GX Features

Architectural

Feature

Results

Altera’s third-
generation FPGA
with embedded
transceivers

Provides a robust design solution for the most popular high-speed serial interfaces

Provides optimum jitter performance across the entire operating range of 622 Mbps to
6.375 Gbps

Provides best-in class signal integrity performance

Offers enhanced transmit pre-emphasis technology, programmable receiver
equalization, and output voltage control

Innovative clock
management
system

Clock signals are automatically routed to the appropriate destination

Greatly simplifies high-speed board designs

Internal clock frequency of up to 500 MHz

Based on the
1.2-V, 90-nm
SRAM process

Provides up to 6.7 Mbits of on-chip TriMatrix

memory

Provides up to 63 DSP blocks for efficient implementation of high-performance filters
and other DSP functions

Supports a wide range of external memory interfaces
