Commands Execution
ViewCheck on ATCA-7470/7475 Installation and Use (6806800S49C) 85
5.5 InService Monitoring Specifics
The In Service Monitoring of ViewCheck provides functionality to:
 Monitor HW Device Status
 Monitor Device Critical Errors
The functionality and access methods provided are briefly described in this section.
5.5.1 Monitoring HW Device Status
In Service Monitoring also periodically polls for various devices status on the blade. These are
 Storage Device HDD Health Status
 Network Devices Counters Statistics
 Network Devices Error Statistics
Each of the above is identified by a unique Monitor ID. For more information on Monitor ID,
refer
Monitor ID on page 19 .
The Default Poll Interval for monitoring each of the Monitor ID is set to 10 Seconds.
Commands are provided to alter the default settings.
For more information on the commands provided for InService Monitoring, refer Monitoring
Commands on page 70 .
The following table provides list of Monitor IDs and Device Instances for each of the Monitors
being monitored on ATCA-7470/7475.
Table 5-28 Monitors
Monitor Description
Monitor
ID
Valid Device Instances Remarks
CPU Core
Temperatures 1000 Core 0 to Core 19 (0 to
15) Temperature of the 16 cores
available on ATCA- 7470 CPU and
20 cores available on ATCA-7475
CPU are monitored individually
and reported if crosses a Set
Threshold.
