Short Seam Automat 2110-4 / 2111-4 Workinging Instructions
- D 84 -
Beisler Automated Sewing Equipment
D.3
Programming
Switching clamp position after end of seam on or
off:
If this function is enabled, the closed clamp moves to the
clamp transport end point after the end of the seam be-
fore releasing the sewing piece. To enable or disable this
function:
8
• Press
 key.
Moving clamp to waiting position:
If this function is enabled, the clamp moves to the waiting
position (e. g. special parameter 05: 48 cm).
P
• Press
 key.
D.3.9 Level 5 special parameters / Functions
Level 5 submenus
& <; 8P

F1 Back to level 4
F3 Switch top thread monitor on or off
F4 Switch rest thread monitor for lock stitch upper part
or bottom thread monitor for chain stitch upper part
on or off
F6 Clamp position after end of seam
F7 Clamp waiting position
Switching the top thread monitor on or off:
For testing purposes, the top thread monitor can be swit-
ched off. To switch the top thread monitor on or off:
<
• Press  key.
NOTE - Operation without top thread monitor!
During normal production, the top thread monitor should
always be switched on as otherwise the sewing programm
will not be stopped if the thread breaks.
Switching the rest thread monitor or bottom thread
monitor on or off:
Depending on the specifications of the sewing head, the
machine is equipped with either a rest thread monitor (for
lock stitch upper part) or a bottom thread monitor (for chain
stitch upper part). Both monitors can be switched on or
off for testing purposes. To switch a monitor on or off:
;
• Press  key.
NOTE - Operation without thread monitor!
During normal production, the rest thread monitor or the
top thread monitor should always be switched on as other-
wise the sewing programm will not be stopped if the thread
breaks.
