- D 87 -
Short Seam Automat 2110-4 / 2111-4 Workinging Instructions Beisler Automated Sewing Equipment
D.4
Factory settings
D.4.1 Factory settings for global parameters
M01 Global parameters 2110-4 / 2111-4:
Pos. global parameters 2110-4 / 2111-4 Value Unit
01 Till CLAMP SIDEWAYS FWD 0.0 sec
02 TILL CLAMP DOWN 0.2 sec
03 TILL VACUUM OFF 0.0 sec
04 THREAD LENGTH spool full 004 m
05 TILL CLAMP INSERTING 0.1 sec
06 SEWING END ->CL.SIDEW. 0.0 sec
07 TIME AFTER CLAMP OPEN 0.1 sec
10 TILL FOLDING CL. CLOSED 0.5 sec
11 TILL FOLDER LIFT UP 0.3 sec
12 TILL FOLDER SWINGS LEFT 0.3 sec
13 IMPULS FOLDER DOWN 0.04 sec
14 CL.OPEN TILL FOLDER UP 0.20 sec
17 TILL TENSION OPEN 0.00 sec
18 DURATION OF TENS. OPEN 0.5 sec
19 TILL THREAD CLAMP FORW 0.1 sec
20 DUR.THREAD CLAMP FORW 0.5 sec
21 TILL STACKER TRANSPORT 0.0 sec
22 DUR.SLIDING TABLE OPEN 0.8 sec
23 LIFT.TABLE MOD 00/01-99 00
24 DUR.LIFTING TABLE SINKS 0.99 sec
35 THREAD CATCH. "UP" POS 200 INC
36 SWITCH ON POS.OF TRIMM 100 INC
37 TRIMMING SPEED 180 Upm
38 DURATION OF TRIMMING 0.35 sec
39 THREAD CATCH.TURNS BACK 00 INC
40 PROCESS IN STEPS 00
