4.4 INLINE METER START-UP AND COMMISSIONING
Please read the entire procedure carefully before proceeding. Wiring diagrams are located in the
appendix. A worksheet for checking off the following steps and recording measured values is
located on the following pages.
1
Confirm meter location
and adequate straight
pipe run to achieve
desired results.
Is the meter located in the correct location as required by the plans?
Compare actual straight pipe upstream and downstream of the meter location to recommended distances
identified in the installation manual. If straight pipe run is very short, consult ONICON PRIOR to installing
the meter.
2
Confirm control system
programming. Confirm that the control system input point is properly configured for the analog range (or digital pulse
factor) identified on the flow meter calibration tag & certificate
3
Confirm connection
to correct ONICON
display or BTU Meter
(if ordered).
Confirm that the flow meter serial number matches the ONICON display or BTU meter serial number (when
ordered together).
4
Verify wiring before
connecting power.
Prior to connecting the power, verify that the wiring is correct as shown in this manual (and/or with the
additional wiring diagram provided with ONICON display or BTU meter.) If in doubt, call ONICON for
assistance before proceeding further.
5
Confirm correct supply
voltage.
Verify that 24 (+/- 4) V is available. Serial Numbers 115692 and later can accept 24 V DC or AC, but earlier
meters required 24 VDC. Note: ONICON display module or BTU meter provide 24 VDC to the flow meter.
ONICON display modules and BTU meters are typically powered by 120 VAC; however, low voltage versions
are also available.
6 Connect power. Wait approximately 45 seconds after power-on before proceeding further.
The following steps require flow in the pipe. Flow signal readings should be taken while holding the flow rate constant if possible;
otherwise, take the various output readings as quickly as possible.
7
Measure and
record frequency
output(s):
The frequency output signal is a 0-15 VDC pulsed output ranging up to500 Hz and must be measured with a
frequency counter or oscilloscope. Measure DC frequency (Hz) from GREEN(+) to BLACK(-). Also measure
DC volts on same wires. Five to seven VDC is normal for a spinning turbine, 0 or 14+ VDC indicates a
stopped turbine. (1 to 4 VDC could indicate a problem)
GPM = Frequency in Hz X 60
Meter Factor in ppg (refer to calibration tag for meter factor)
8
Measure and record
analog or digital
outputs.
Current Output:
Voltage Output:
Divided Output:
Scaled Output:
Refer to flow meter wiring diagram for wire colors for the various outputs available based on your particular
flow meter model. Use the following formulas to calculate flow rate from measured analog signals:
GPM = (measured current in mA - 4) X Full Scale Analog Flow Rate
16
GPM = measured DC volts X Full Scale Analog Flow Rate
10
Same calculation as step 9, except use “divided meter factor” (measure and record frequency)
Each contact closure = unit volume identified as “Scale Factor” (measure and record time interval between
contact closures.)
9
Compare various
output signals to each
other and to the flow
rate displayed by the
control system.
Compare the flow rates calculated in STEPS 7 and 8 to each other and to the flow rate indicated by the
control system. Refer to troubleshooting guide when readings are inconsistent.
End of standard start-up and commissioning. Please contact ONICON at (727) 447-6140 with any questions.
