System-10 BTU Meter Manual 03/15 - 0651-16 / 18323 Page 8
SECTION 2.0: UNPACKING
The SYSTEM-10 is generally shipped in one package unless optional hardware or equipment is
ordered. (Thermowells may have been shipped in advance.) Notify the freight carrier and ONICON if
any items are damaged in transit.
NOTE: Flow meters are packed separately.
2.1 CHECKING THAT YOU HAVE RECEIVED EVERYTHING
• Standard Documentation
Enclosed with each SYSTEM-10 is a comprehensive documentation package that includes
the following items:
The SYSTEM-10 BTU Meter Installation and Operation Guide
The BTU Meter Certificate of Calibration
Please notify ONICON if any of these items are missing.
i
IMPORTANT NOTE
The ONICON System-10 BTU Measurement System is a custom calibrated system. Unless
specifically noted in writing by ONICON, ALL COMPONENTS (Btu meter, flow meter, and
temperature sensors) share the same serial number and must be installed together as a system.
Mixing components from different systems will result in significant errors in calibration.
• The Main Unit
Remove the SYSTEM-10 from the shipping carton and inspect it for physical damage. When
you complete the external inspection, open the SYSTEM-10 main unit and remove the
plastic bag containing the temperature sensors. Inside the main unit there are at least three
circuit boards (the number may vary according to the options purchased). Ensure that the
boards and connectors are securely plugged into the mother board (Appendix A-14). Please
notify ONICON immediately if you find any discrepancies.
• Temperature Sensors
Temperature sensors are shipped inside the main unit. Inspect the sensors and cables for
external damage. Each sensor should have a label attached with a serial number identical to
that found on the SYSTEM-10 main unit.
• Temperature Thermowells
Note that thermowells and installation hardware are frequently shipped in advance of the
meter(s). Otherwise, the standard thermowells and installation hardware are packed with the
main unit. Optional hot tap thermowells will be shipped in a separate box.
• The Flow Meter
The flow meter calibrated with this Btu meter came complete with an instruction manual.
Please refer to the flow meter instruction manual for detailed information regarding the
installation, commissioning, and operation of the flow meter.
Each Btu meter is calibrated to a specific flow meter and must be used together as a system.
If the flow meter and Btu meter were purchased together, the serial number on the flow meter
should match the serial number on the label mounted directly on the Btu meter.
