OpenEye OE3 E-Series - Manual (Page 75)

29716AG 75
1. Click the Calendar icon to open the calendar and select a date.
2. Select a time using the hour and minute control bars.
3. Select one or more cameras.
4. Click Play . (Video can be played forwards, backwards, or frame-by-frame.)
The Status Search option displays a timeline in graph format. Scroll through multiple cameras
and easily locate hours with recorded video.
Performing a Status Search
1. In Search mode, click Status .
2. Click the Date button to open the calendar and select a date.
3. Click along the orange recorded video block to select a desired camera or time frame.
4. After locating the desired video, close the Status Search window and use the playback
controls to play forward, reverse or frame-by-frame.
The E240 and E480 recorders can record video using one of three different resolutions.
When using the 704 x 480 resolution, two fields are mixed. Because of the timing gap
between the two fields, according to the standardized image rules, after image might occur to
high speed moving images. The recorder allows the user to remove this by clicking Clean
Image.
Cameras
24 Hours (0-23) AM & PM
Recorded video displayed in Orange
