Compact HMI and Compact HMI Editor Operations Manual
Super Systems Inc.
Page 32 of 60
Y
Y coordinate of upper left
corner of control
Size
The size of the control in pixels.
Width
Width of the control in pixels
Height
Height of the control in pixels
Table 7 - Control Button properties
Image Box
Figure 27 - Image Box
The Image Box is used to display graphics on the panel. It will not be tied directly to data.
However, like all other controls, its properties can be modified through conditional formatting.
Image Box properties are described in Table 8. An example properties grid is shown in Figure 28.
