ENR-
1000 Series System Administrator’s Manual
22
Install the Hard Disks
This system requires at least one hard disk to store video recordings and firmware image
when upgrading system. Please follow the instructions below to install your hard disks in
correct order to make sure the physical disk locations accord with the Disk ID shown in ENR
server’s Storage Device List .
Step 1 Remove the Case Cover
Remove the four front
panel screws, and then
remove the three back
panel screws.
Slide the case backward
until it stops, and then lift it
up to remove.
Step 2 Install Disk SATA-2
Insert Disk SATA-2 in the
lower bay, connect SATA
power cable and SATA
data cable 2 to the hard
disk.
Make sure you connect the
correct data cable to the
corresponding disk.
