The Edit Timeline
Profile Family 273
The Edit Timeline
The edit timeline lets you edit masters and their tracks of video and
audio (up to sixteen tracks of audio). The current frame is indicated
by the placement of the current position (time) cursor. The
horizontal scroll bar allows you to scroll through time, and the vertical scroll
bar allows you to scroll through tracks. Select the
Edit button beneath the audio
controls to activate the edit timeline without changing the current time position.
Figure 130. Edit timeline
Beneath the edit timeline is a toolbar displaying these buttons:
• Zoom-in: Zooms in the track scale.
• Zoom-out: Zooms out the track scale.
You can insert clips at the edit closest to the current time position by choosing
Insert from the Media menu or from the shortcut menu with a right-click, or by
clicking Insert Media on the current bin toolbar.
Zoom-In
Zoom-Out
Scroll Bars
Linear Timecode
Readout
Track
Readouts
Current Position (Time) Cursor
Track Labels
(1 Audio, 2 Video)
Master Name
Trim Handles
Selected Clip
