Ricoh Pentax КP - Manual (Page 55)

3
Shoo
ting
53
6
Press 0 fully again.
Movie recording stops.
u Caution
• When recording a movie with sound, camera operation
sounds are also recorded. When [AF Mode] of [AF with Live
View] in the C1 menu is set to y, the focus operation
sounds are recorded. Adjusting the sound volume in
[Recording Sound Level] of the C1 menu, or using an
external microphone can reduce the operation sounds to be
recorded. When [Recording Sound Level] is set to [Manual],
the sound volume can be set from 0 to 20.
• When recording a movie with an image processing function
such as Digital Filter applied, the movie file may be saved with
some frames omitted.
• If the internal temperature of the camera becomes high
during recording, recording may be terminated.
• When a retractable lens is attached, recording stops if the
lens is retracted during recording and an error message is
displayed.
t Memo
• You can record a movie continuously up to 4 GB or
approximately 25 minutes. When the memory card is full,
recording stops.
• You can change the settings for movie recording in the C
menus. (p.29)
• By default, autofocus is not performed when 0 is
pressed halfway during movie recording. If a compatible lens
is attached to the camera, you can select y in [AF Mode]
of [AF with Live View] in the C1 menu and continuously
autofocus even during movie recording. (p.62) When [AF
Mode] is set to y, the f button operation varies as
follows depending on the setting assigned to f in [Button
Customization] of the C2 menu. (p.102)
u Caution
• Do not connect a microphone or other device outside the
recommended specifications to the microphone/cable
release terminal. Also, do not use an external microphone
with a 3-meter or longer cable. Doing so may cause the
camera to malfunction.
• If an external microphone is used when recording a movie
with the Wi-Fi™ function enabled, radio noise may be
recorded depending on the compatibility with the microphone.
[Button Customization]
setting
Autofocus operation when f
is pressed
Enable AF1,
Enable AF2 Pressing f performs autofocus
based on the [AF Mode] setting.
Cancel AF
Pressing f stops autofocus
and pressing f again restarts
autofocus.
Using a Microphone or Cable Release
You can connect a commercially
available stereo microphone to
the microphone/cable release
terminal on the camera. Using an
external microphone can also help
to reduce the possibility of
recording camera operation
sounds.
The following specifications are
recommended for external microphones. (A monaural
microphone cannot be used with this camera.)
You can also connect the optional Cable Switch CS-310 to
the microphone/cable release terminal on the camera. When
the cable release is connected, sounds are recorded with the
built-in microphone.
You can set the device to connect
in [External Input Devices] of the
D
3 menu. Normally, you do not
need to change the default setting
([Auto Select]).
Microphone/cable
release terminal
Plug Stereo mini plug (ø3.5 mm)
Format Stereo electret condenser
Power
Plug-in Power Method (operating
voltage of 2.0 V or lower)
Impedance 2.2 kΩ
Automatically detects input Automatically detects input
device and switches between
device and switches between
cable release and microphone
cable release and microphone
External Input Devices External Input Devices
External Input Devices External Input Devices
Cancel Cancel OK OK
