3
Shoo
ting
61
2
Select the desired AF
point.
Available operations
t Memo
• In R mode, [AF Active Area] is fixed to [Auto (27 AF
Points)].
• The [AF Mode] and [AF Active Area] settings can be checked
also in the viewfinder. Q is displayed in the viewfinder when
the AF point can be changed. (p.19)
• You can switch the function of the arrow keys to AF point
change mode with X, Y, or Z, instead of pressing and
holding E. (p.102) When [Change AF Area] is assigned to
X
, Y, or Z, the operation by pressing and holding E is
disabled.
• You can select the button operation when changing the AF
point in [18 4-way Controller Settings] of the E3 menu.
The autofocus operation when shooting with Live View can be
set in [AF with Live View] of the A1 and C1 menus.
t Memo
• The [AF Mode] and [AF Active Area] settings can be changed
by turning Q or R while pressing b. (p.62)
• When [AF Mode], [AF Active Area], or [Focus Peaking] is
assigned to the function dial, you can change the setting
using the Smart Function. (p.21, p.105)
• When [Focus Peaking] is set to [Highlight Edge] or [Extract
Edge], the outline and contrast of the subject in focus is
emphasized, and this makes it easier to check the focus. This
function works in both v and w modes. The outline of the
subject is not emphasized while autofocus is performed or a
movie is recorded. Histogram Display and Highlight Alert
become inactive while the outline of the subject is
emphasized.
ABCD Changes the AF point.
E Returns the AF point to the
center.
Press and hold E Switches the function of the
arrow keys (ABCD) to AF
point change mode or direct
key operation mode.
Type1
Switches the function of the arrow keys alternately
between AF point change mode and direct key
operation mode.
Type2
Prioritizes the AF point change mode in standby
mode.
1/ 1/ 250 250
1600 1600
FF 5.6 5.6
99999 99999
Setting the Autofocus when
Shooting with Live View
A 1/C1
AF Mode x , y
AF Active Area
Face Detection, Tracking, Multiple AF
Points, Select, Spot
Focus Peaking Highlight Edge, Extract Edge, Off
AF.S Setting
Focus-priority, Release-priority
AF Active Area AF Active Area
AF Mode AF Mode
Focus Peaking Focus Peaking
AF with Live View AF with Live View
AF Active Area AF Active Area
Focus Peaking
Focus Peaking
AF.S Setting
AF.S Setting
AF with Live View AF with Live View
