Features, Functions and Specifications Sorensen Ethernet Option
1-4 M130/131 Programming Manual
1.3.2 E
THERNET
C
ONFIGURATION
F
ACTORY
D
EFAULTS
PARAMETER DEFAULT
Host Name S-Dxx<base model>-<last four digits of serial number>
Description Sorensen Power Supply Dxx<base model>
IP Address
DHCP-acquired (Primary default*) If DHCP absent,
assigned via Auto-IP (Secondary default*)
IP Addressing mode DHCP-acquired (Primary default*)
Subnet Mask
DHCP-acquired (Primary default*) If DHCP absent,
assigned via Auto-IP (Secondary default*)
Gateway 0.0.0.0
DNS Server 0.0.0.0
Listening Port 9221
User ID admin
Password password
Ping Echo On
* The Ethernet interface provides the opportunity to set both a Primary and a
Secondary IP configuration in the IP Configuration page (Section 2.4.4). If the
Primary fails, the system defaults to the Secondary configuration. However, both
setting DHCP-acquired and selecting “Auto IP Enabled” together in the Primary
configuration, prevents the power supply from trying the Secondary configuration.
Please see “IP Configuration” in Section 2.4.4 for more detail.
1.3.3 P
ROGRAMMING
R
ESOLUTION
DLM DCS
Voltage 0.002% of full scale 0.002% of full scale
Current 0.002% of full scale 0.002% of full scale
Overvoltage Protection
0.002% of full scale (full
scale is 110% of max
output voltage.) 0.002% of full scale (full
scale is 110% of max
output voltage.)
1.3.4 P
ROGRAMMING
A
CCURACY
DLM600 DCS
Voltage ± (0.1% of maximum output voltage)
± (0.1% + 0.1% of full
scale)
Current ± (0.25% of full scale output current
± (0.1% + 0.4% of full
scale)
Overvoltage
Protection
± (0.5% of max output voltage)
± (0.5% + 0.5% of full
scale) (full scale 110% of
max. output voltage)
