Configuration Sorensen Ethernet Option
2-4 M130/M131 Programming Manual
6. Set the IP address by typing SYST:NET:IP “xxx.xxx.xxx.xxx” <enter> (where
xxx.xxx.xxx.xxx is the new IP address). For example, to set 192.168.0.200 as the
IP address, type SYST:NET:IP “192.168.0.200” <enter> (note that the format
requires a single space after SYST:NET:IP and double quotes around the IP
address numbers).
7. Set the subnet mask with “SYST:NET:MASK xxx.xxx.xxx.xxx” <enter>.
8. After configuring all settings, verify with the queries, SYST:NET:IP? <enter> and
SYST:NET:MASK? <enter>.
9. Type *RST<enter> to perform a power–on reset of the power supply.
10. The M130 Ethernet hardware is now configured. Open your Web browser and
enter the assigned IP address of the power supply to view the power supply web
page.
11. The power supply is now ready to be plugged into the network.
2.1.4 M130 N
ETWORK
S
ETUP
U
SING
W
EB
B
ROWSER
Note: This requires that the PC’s IP address be in the same network as the IP
address assigned to the power supply. It also requires your Web browser to open
the power supply’s Home page.
Note: For proper functionality on the Web browser, ensure that Sun Microsystems’
Java Runtime Environment is installed on the PC. Visit www.java.com to download,
after setting the Web browser’s Security to enable scripting of Java applets:
1. In the Tools menu, select Internet Options… and click the Security tab.
2. At the bottom of the Security window click Custom level…
3. In the Reset custom settings drop-down, select Medium and click Reset
and then OK).
Now use your Web browser for M130 Network Setup:
In the Web browser’s Address: field, type http://xxx.xxx.x.xxx where
xxx.xxx.x.xxx is the power supply’s IP address. (See Section 2.4.4 for
description and operation information).
