Sorensen Ethernet Option Configuration
M130/M131 Programming Manual 2-17
• Host Name: the default name includes the base model number of your
power supply, with the last four digits of the serial number. You may
change this name as long as it is unique so that VXI-11 Discovery and any
other IP Discovery program can identify your specific device on your
network.
To change: Type the new name (15 characters maximum) in
the blank field provided and click Apply to update
(or make all desired changes before clicking
Apply).
• Description: you may change the default factory setting to something
more meaningful to your current setup.
To change: Type your customized description, up to 64
characters, in the blank field provided, and click
Apply to update (or make all desired changes
before clicking Apply).
TCP/IP Configuration: the power supply has two TCP/IP
configurations that can be set, Primary and Secondary. If the
Primary Configuration is not valid on your network, the power supply
will attempt to try the Secondary Configuration.
NOTE: The power supply will NOT try the Secondary Configuration if
you have selected the Primary Configuration options, Obtain an IP
Address Automatically and Auto IP Enabled.
You may statically assign an IP address as well as configure other
Ethernet/LAN parameters, or you may keep/return to its default
setting for automatic assignment of an IP address.
To assign: Click the radio button next to Use a Static IP
Address to manually configure some or all of the
following the Ethernet/LAN parameters:
IP Address – input any standard IP address.
(Factory setting is 192.168.0.200). After clicking
Apply, you also must reset the power supply and
then exit and restart the Web browser to effect this
change. If you have changed the network portion of
the IP address, it may be necessary to alter the
network settings of your attached computer to
reconnect to the power supply.
Subnet Mask – input a value that identifies which
network segment your power supply is on, consisting
of 4 whole numbers, each ranging from 0 through
255, separated by periods. (Factory setting is
255.255.255.0, a class-C network subnet mask).
Click Apply to update (or make all desired changes
before clicking Apply).
Gateway – input the IP Address of any gateway that
stands between the instrument and any other
