IEEE 488.2 and SCPI Command Operation Sorensen Ethernet Option
3-16 M130/131 Programming Manual
3.7 OUTPUT SCPI C
OMMAND
S
UBSYSTEM
3.7.1 OUTPUT SCPI C
OMMAND
S
UMMARY
OUTPut[n]
:ISOLation <boolean>
:POLarity <NORM/0/OFF|INV/1/ON>
:PROTection
:DELay <0+NRf>
:FOLD <0|1|2>
:SENSe <boolean>
:STATe <boolean>
:TRIPped?
3.7.2 OUTPUT SCPI C
OMMAND
R
EFERENCE
Command Description SCPI
OUTPut[n] Output subsystem. n = 1-31. The default
channel is 1. C
:ISOLation <boolean> Sets the rear panel isolation relay control
signal ON or OFF. Valid arguments are
1/ON or 0/OFF. N
:POLarity <NORM/0/OFF|INV/1/ON> Changes the state of the polarity relay. This
command requires that the isolation relay be
open beforehand. If the isolation relay is
closed when this command is attempted, the
state of the polarity relay will not change,
and an error message will be generated.
:PROTection N
:DELay <0+NRf> Sets the programmable time delay executed
by the supply before reporting output
protection conditions after a new output
voltage or current is specified. N
:FOLD <0|1|2> Sets the foldback (program down) mode of
the supply. Valid arguments are 0 (OFF or
do nothing, do not program down to zero), 1
(program down to zero upon entering
constant-voltage mode), or 2 (program down
to zero upon entering constant-current
mode). N
:SENSe <boolean> Sets the sense relay signal open or close.
Valid arguments are 1/ON or 0/OFF. N
:STATe <boolean> Sets the output to zero or the programmed
value; opens or closes the isolation relay.
Valid arguments are 1/ON or 0/OFF. *RST
state value is ON. CAUTION: Ensure that
suitable delays are incorporated to preclude
hot switching of the isolation relay. C
:TRIPped? Returns the integer value 1 (TRIPPED) or 0
(UNTRIPPED) state of the output. N
