Wiring
Page 5-28 MDE-4340A Series 9800Q Pumps and Dispensers Installation/Operation Manual · January 2006
2 See Weights and Measures Handbook 44 to determine which mode of satellite operation is
relevant for your application. In many cases, the satellite must be wired so it cannot dispense
product while the master remote dispenser is dispensing and vice versa. Use the correct wiring
diagram according to your application.
3 The input line CONTROL/SUBM FEED is comprised of two wires which are tied together at
the factory.
CAUTION CAUTION
To avoid damage to the CPU PC board, all unused wires must be individually capped,
and before applying power, you must verify that the RESET COMPLETE, FAST
FLOW, SUBM. STARTER DRIVE, SLOW and FAST SATELLITE RETURN wires
are not shorted to conduit or chassis.
4 SUBM. STARTER DRIVE line can supply 300 mA AC maximum to control submersible
starter relays.
CAUTION
This line must not be directly connected to a submersible pump.
5 External submersible relays are required unless the remote dispenser is equipped with the
submersible drive relay option. The submersible drive relay option provides a SUBM PUMP
DRIVE line (Blue 14) which can directly drive a submersible pump up to 3/4 HP at 115 VAC
or 1-1/2 HP at 230 VAC. The 14 AWG SUBM FEED and SUBM PUMP DRIVE wires are
always present. Verify that the submersible drive relay option is installed prior to wiring. The
power supplied to the CONTROL/SUBM FEED must be able to handle the load of the
submersible pump.
6 If the CONTROL/SUBM FEED line is controlled by a fuel management system using solid
state relays, a resistor assembly must be installed between the Control Feed line and Feed
Neutral to prevent false triggering of the authorization input. The resistor assembly is 8.2K
OHM, 10 Watt (P/N C05818) for 115/230 VAC domestic and 30K OHM, 10 Watt (P/N
C06683) for 230 VAC international wiring.
7 The FAST FLOW line (pink wire) is supplied from the factory disconnected. It must be
connected, in the upper junction box, to the pink wire (fast flow control) coming from the
electronic platform assembly.
8 If using a GASBOY 9800Q and satellite in an application where both master and satellite
cannot dispense product at the same time, a minor change in the 9800Q wiring must be made.
In the solenoid J-Box, disconnect the solenoid yellow wire from the two orange wires (leave
the two orange wires connected together). Connect the solenoid yellow wire to the 18 AWG
brown wire. In the solenoid junction box, disconnect the solenoid black wire from the two
pink wires (leave the two pink wires connected together, as described in note 5). Connect the
solenoid black wire to the 18 AWG yellow wire. Wire the remote dispenser to the satellite as
shown in the wiring diagram labeled Non-Simultaneous.
9 If this unit is equipped for 230 VAC operation (international), wire as shown in the standard
115 VAC wiring layout diagram.
10 These wiring diagrams are intended only to show the connections between the satellite and the
dispenser. See wiring diagram for master dispenser (according to model number) for
applicable warnings and proper connection of all wires.
