MDE-4340A Series 9800Q Pumps and Dispensers Installation/Operation Manual · January 2006 Page 1-3
Introduction
• Submersible drive relays capable of handling 3/4 HP at 115 VAC or 1-1/2 HP at 230 VAC
• Fluorescent lighting for the faceplate and brand panel
Document
Number
Document Title GOLD Library
035286 215A/216A Installation /Operation Manual Gasboy Commercial & Retail Pumps
C01918 CFN Site Controller II Installation Manual. Gasboy Fuel Management Products
C35628 Fuel Point Reader Installation and Retrofit Manual Gasboy Fuel Management Products
C35963 CFN Series Islander II Installation Manual Gasboy Fuel Management Products
MDE-4298 CFN Site Controller I Installation Manual Gasboy Fuel Management Products
MDE-4344 Series 1000 Installation Manual Gasboy Fuel Management Products
Related Documentation
Acronym Table
The following table contains a list of acronyms used in this manual.
Note: Refer the glossary section for more detailed definitions.
Acronym Definition
AC or ac Alternating Current
ASC Authorized Service Contractor
AWG American Wire Gauge
CFR Code of Federal Regulations
CPR Cardiopulmonary Resuscitation
CPU Central Processing Unit
CSA Canadian Standards Association (Canadian equivalent of UL)
DC (or dc) Direct Current
DIP Dual In-line Package
DLT Displaying Last Transaction
FMS Fuel Management System
FPR Fuel Point Reader
GPM (or gpm) Gallons Per Minute
HP Horse Power
IFSF International Forecourt Standards Forum
LPM Liters Per Minute
MOC Major Oil Company
NEC National Electrical Code
NFPA National Fire Protection Association
OSHA Occupational Safety and Health Association
PCB Printed Circuit Boards (preferred term: board)
POS Point Of Sale
PPG Pulses Per Gallon
PPL Pulses Per Liter
PPP Programmable Pump Preset
RS Request-to-Send (modem application)
