Instructions for programming the
Waterwash Control Panel (WWCP)
24-hour or 7-day timer
If your waterwash control panel included a timer, either 24-hour or 7-day, it will need to be
programmed prior to kitchen start-up. The timer was shipped with a 3-year battery installed
and was tested before leaving the factory.
The function of the timer is to start the hood wash sequence after all cooking and dish
washing operations have ended for the day, so that all available hot water may be used in
washing the hood baffles.
The daily sequence of operations is:
1. Press the “Start Fan” button at the beginning of the day to start the fans.
2. Press the “Stop Fan / Start Wash” button at the end of the day to stop the fans.
A. This will initiate the wash timing delay
B. To wash the hood immediately, press the “Stop Fan / Start Wash” button a second time.
3. After all wash sequences have been completed, the WWCP will reset for the next day’s operation.
Programming Instructions:
1. Remove the clear plastic cover over the 6 buttons by gently lifting out at the top.
2. Press the “MODE” button until “CLK” is displayed in the upper left corner.
3. Press the “DAY” button until the correct day is shown at the bottom of the display.
4. Press the “H+” and “M+” buttons to set the correct time. “AM” or “PM” is shown at the left side of the
display.
5. Press the “MODE” button once. “PRG” should be displayed.
A. On the right side of the screen should be a “1” and “ON”. This is the first program.
There are 6 available to use. Normally only one is used for 24-hour timing and the other 5 can be used
for 7-day timing.
B. With 24 hour timing, the wash cycle will start the same time everyday.
6. Press the “DAY” button until the correct day or days appear at the bottom of the display. Use “MO TU WE
TH FR SA SU” for 24 hour timing.
7. Press the “H+” and “M+” buttons to set the time the wash is to start.
8. Press the “ON/OFF EVENT” button once. “OFF” and “1” should be on the right of the display.
9. Set the off time to be 5 minutes after the on time for this program.
10. If using as a 7-day timer, use the “ON/OFF EVENT” button and repeat steps 6-9 to set the other programs
as needed.
11. Press the “MODE” button once. “AUTO” should be displayed.
12. Replace the clear plastic cover over the buttons.
13. The hood may also be manually washed any time the fans are off by pressing the clear plastic button
cover. “ON” should appear on the right side of the display.
