6.4.4 Resolution of original GF-100 EDID
Menu
TOP → EDID OUT → RESOLUTION
Set value [Default: 1080p]
[Table 6.4] EDID output data
VG
A
640 x
480
S
VG
A
800 x
600
XG
A
1024 x
768
720p
1280 x
720
W
X
G
A-
1
1280 x
768
W
X
G
A-
2
1280 x
800
Qu
ad
-
V
GA
1280 x
960
SXG
A
1280 x
1024
W
X
G
A-
3
1360 x
768
W
X
G
A-
4
1366 x
768
SXG
A
+
1400 x
1050
W
X
G
A+
1440 x
900
W
X
G
A+
+
1600 x
900
U
XG
A
1600 x
1200
W
SXG
A
+
1680 x
1050
1080i
1920 x
1080
1080p
1920 x
1080
W
U
XG
A
1920 x
1200
QW
X
GA
2048 x
1152
SVGA ● ●◎
XGA ● ● ●◎
720p ● ● ● ◎
WXGA-1 ● ● ● ○ ◎
WXGA-2 ● ● ● ○ ◎ ○◎
Quad-VGA ● ● ● ○ ◎ ○ ◎
SXGA ● ● ● ○ ◎ ○ ○ ●◎
WXGA-3 ● ● ● ○ ◎ ○ ○ ●○ ◎
WXGA-4 ● ● ● ○ ○ ○ ●○ ◎ ◎
SXGA+ ● ● ● ○ ○ ○ ●○ ◎ ◎
WXGA+ ● ● ● ○ ○ ○ ●○ ◎ ○ ◎
WXGA++ ● ● ● ○ ○ ○ ●○ ◎ ○ ○ ◎
UXGA ● ● ● ○ ○ ○ ●○ ◎ ○ ○ ○ ◎
WSXGA+ ● ● ● ○ ○ ○ ●○ ◎ ○ ○ ○ ○ ◎
1080i ● ● ● ○ ○ ●○ ◎ ○ ○ ○ ○ ○ ◎
1080p ● ● ● ○ ○ ●○ ○ ○ ○ ○ ○ ◎ ◎
WUXGA ● ● ● ○ ○ ●○ ○ ○ ○ ○ ○ ◎ ◎
QWXGA ● ● ● ○ ●○ ○ ○ ○ ○ ○ ◎ ○ ◎
S
e
t val
u
e
Supported resolution
●:Established Timing / ○:Standard Timing Identification / ◎:Detailed Timing Description
VESA Enhanced EDID Standard Release A, Rev1
6.4.5 Color depth of original GF-100 EDID
Menu
TOP → EDID OUT → COLOR DEPTH
Set value
24 bit [Default]
24/30 bit
24/30/36 bit
