GF-100 User’s Guide
42
7.3.4 Test pattern HDCP
Menu
TOP → TEST PATTERN → HDCP OUT
Set value
AUTO: automatic [Default]
OFF: without HDCP
ON: with HDCP
7.3.5 Test pattern format/color space
Menu
TOP → TEST PATTERN → FORMAT
Set value
AUTO: automatic [Default]
DVI
HDMI RGB
HDMI YCbCr4:2:2
HDMI YCbCr4:4:4
7.3.6 Test pattern color depth
Menu
TOP → TEST PATTERN → COLOR DEPTH
Set value
AUTO: automatic [Default]
8 bit: 24 bit/pixel (8 bit/component )
10 bit: 30 bit/pixel (10 bit/component )
12 bit: 36 bit/pixel (12 bit/component )
Note: If “7.3.5 Test pattern format/color space(P.42)” is set to “DVI”, “8 bit” will be applied automatically.
