[Table 9.1] Measurement results (example)
Cable Resolution Color depth [bit] Number of test bits
Number of bit
errors/Result
20 m or shorter
(without equalizer)
480p
8 8294400 0
10 10368000 0
12 12441600 0
720p
8 22118400 0
10 27648000 0
12 33177600 0
1080p
8 49766400 0
10 62208000 0
12 74649600 0
30 m
(without equalizer)
480p
8 8294400 0
10 10368000 0
12 12441600 1290
720p
8 22118400 6
10 27648000 19
12 33177600 30884
1080p
8 49766400 0
10 62208000 SYNC FAILED
12 74649600 SYNC FAILED
50 m
(without equalizer)
480p
8 8294400 2761826
10 10368000 SYNC FAILED
12 12441600 SYNC FAILED
720p
8 22118400 SYNC FAILED
10 27648000 SYNC FAILED
12 33177600 SYNC FAILED
1080p
8 49766400 DISCONNECTED
10 62208000 DISCONNECTED
12 74649600 DISCONNECTED
30 m or shorter
(with equalizer)
480p
8 8294400 0
10 10368000 0
12 12441600 0
720p
8 22118400 0
10 27648000 0
12 33177600 0
1080p
8 49766400 0
10 62208000 0
12 74649600 0
