GF-100 User’s Guide
46
WEB page
http://The GF-100’s IP address/pass_ddc_r.html : Displays the protocol of EDID and HDCP
http://The GF-100’s IP address /pass_ddc_raw_r.html : Displays the DDC communication data
● The history data of the DDC monitoring data is kept even after turning off the GF-100.
● When no space is available in the save area of communication history (56,320 byte), from the oldest data
will be deleted.
[Fig. 8.3] WEB page for monitoring DDC
Menu
TOP → DDC MONITOR → STATUS
The simplified communication status is
displayed.
[Fig. 8.4] Simplified display
T O P > D D C M O N I T O R [ 1 / 3 ] S T A T U S
H P : 4 . 8 4 V E D I D :
D D C : 5 . 0 1 V H D C P :
O T H E R S :
