Congratulations on choosing a Kreg Foreman Semi-Automatic Pocket-Hole Machine!
Be sure to read the instructions and the safety warnings completely before using this machine.
Table of Contents
TABLE OF CONTENTS 1
SAFETY GUIDELINES 2-6
ASSEMBLY INSTRUCTIONS - DB110 7
ASSEMBLY INSTRUCTIONS - DB55 8
DB110 (Electric Model) 9-12
General Operations/Maintenance 9
Adjusting the EZ DB Fence 10
Adjusting the Drill Bit Depth Stop/Clamping Pad Height 11
Swing Stops/Changing the Drill Bit 12
DB55 (Pneumatic Model) 13-16
General Operations/Maintenance 13
Adjusting the EZ DB Fence 14
Adjusting the Drill Bit Depth Stop/Clamping Cylinder Height/Automatic Lubricator 15
Swing Stops/Changing the Drill Bit 16
Warranty 17
Notes 18
Attention:
As with all machinery, there are certain hazards involved with operation and use of the machine. Using
the machine with respect and caution will considerably lessen the possibility of personal injury. However, if
normal safety precautions are overlooked or ignored, personal injury to the operator may result.
This machine was designed for specifi c applications only. Kreg strongly recommends that this
machine NOT be modifi ed and/or used for any application other than for which it was designed. If
you have any questions relative to its application, DO NOT use the Machine until you have written
Kreg Tool and we have advised you.
Table of Contents
1.
P
Indicates the PHASE (HOT)
wire from the powersource
N
Indicates the NEUTRAL
wire from the powersource
!
Caution,
refer to manual
Earth Ground
Connection
Make sure all power sources have been disconnected
from this machine before opening the electrical box.
Symbols:
