• Low-resolution proxy files created during record and live streaming from SDI In/out are available
as part of the AppCenter Pro and Elite licenses
• RAID media storage
• Stand-alone internal storage, stand-alone external direct-connect storage, and external shared
(SAN) storage
Product identification K2 Summit 3G
The K2 Summit 3G system has labels affixed to the chassis that provide product identification as
illustrated:
USB compartment
(Clip behind bezel)
Note: removing the bezel takes
the fans offline. Replace the bezel assembly
within one minute to maintain system cooling.
Serial Number
This is also the factory
default hostname
K2 Summit 3G system orientation
The following illustration shows the location of Field Replaceable Units (FRUs) and other components
in the K2 Summit 3G system.
14 November 2012 K2 Summit 3G Service Manual 29
Product description
