3. Once the startup sequence begins, observe the progression of behaviors as listed in the following
table. These are the behaviors you should expect for a normally operating K2 Summit 3G system.
If you observe behaviors other than those listed, refer to the indicated troubleshooting topics to
identify problems.
NOTE: You can press the Pause/Break key on the keyboard to keep startup text on the screen
for longer viewing.
If not, refer to the following:
This behavior should occur…
At about
this time…
on
page 78
Pressing the standby button starts the K2 Summit
3G system.
—
on page
81
Power on LED goes on and stays on.
0 seconds
on
page 78
Service LED stays off.
on
page 80
Front bezel assembly and processor fan start.
on page 79
System BIOS screen appears.
10
seconds
—
Grass Valley logo screen appears.
35
seconds
on page 79
Windows logon screen appears.
70
seconds
Logon to Windows to continue the startup sequence.
After Windows logon:
If not, refer to the following:
This behavior should occur…
At about
this time…
on
page 80
Grass Valley logo desktop appears.
0 seconds
Service LED goes on for a few seconds, then off.
5 seconds
on page 79,
on
page 80
Desktop icons, startbar, and AppCenter logon
box appear.
20
seconds
Logon to AppCenter to continue the startup sequence.
After AppCenter logon:
If not, refer to the following:
This behavior should occur…
At about
this time…
on
page 80
System Startup messages appear.
0 seconds
