3D Transformations and What They Do (NewsEdit XT only)
Digital News Production 291
3D Transformations and What They Do
(NewsEdit XT only)
Each 3D transformation has a different function and different adjustment
controls.
Resize
Enlargement and reduction of the image area while it remains in the same plane
in 3D space.
Locate
You use the Locate transformation to move the image anywhere on the screen.
or to a position partially or completely off-screen.
Option Range Description
X-Position -32 to +32 Moves the image left or right.
Y-Position -24 to +24 Moves the image up or down.
Size 0 to 4 Moves the image closer or farther away.
X-Aspect 0 to 4 Adjusts the image width left to right.
Y-Aspect 0 to 4 Adjusts the image width top to bottom.
Option Range Description
X-Position -32 to +32 Moves the image left or right.
Y-Position -32 to +32 Moves the image up or down.
Z-Position -32 to +32 Moves the image closer or farther away; the image appears larger
or smaller but does not actually change in size.
