3D Transformations and What They Do (NewsEdit XT only)
Digital News Production 295
Axis Locate
You use the Axis Locate transformation to determine the center point of
translations, spins, and rotations for that channel. You can move the axis to a
new location to change the behavior of that channel. The axis location can be
within or outside of the screen area.
Option Range Description
X-Position -32 to +32 Moves the image left or right.
Y-Position -24 to +24 Moves the image up or down.
Z-Position -32 to +32 Moves the image closer or farther away.
