Trinix NXT — Installation and Service Manual 305
Configuration
SNMP license installed on the matrix. The Signal-Loss settings can be
accessed from two places:
• From the Individual Input Board Web Page .
• From the Frame Level Signal Web Page .
Both of these pages are explained in detail below.
From the Individual Input Board Web Page
You can use Grass Valley’s NetConfig application to access each Input
board.
Follow these steps to configure the Input Signal Loss notification feature
using the Individual Input board’s Web Page:
1. Click the Signal button to open the Signal Alarm Configuration page
( Figure 217 ).
2. Select the Signal alarms for each connector.
Figure 217. The Signal Alarm Configuration Page in NetConfig
3. Save the configuration by clicking the Save Signal Alarm Config button
( Figure 218 ).
Figure 218. The Signal Alarm Configuration Page NetConfig
